LPTC Linear Silicon PTC Thermistor Packed in Glass DO35

MF58 DO35 diode package NTC thermistor axial or radial leads for all kinds of vehicle electrical temperature sensor probes

Brand:
Focusens
Item NO.:
LPTC83-110
Order(MOQ):
2000 pcs
Shipping Port:
Shanghai / Ningbo/Hefei/Shenzhen
Lead Time：
4 weeks
Sensing Component:
Linear Silicon PTC Thermistor
Working Temperature:
-40-200'C
Thermal Time:
5s

Inquire now

Categories

New Products

Product Detail

Liner Silicon PTC Thermistor Packed in Glass DO35

MF58 DO35 diode package NTC thermistor axial or radial leads for all kinds of vehicle electrical temperature sensor probes

Technical Data

Size :

Ordering Code:

Part Number	Resistance (Ω)	Tolerance (%)	Operating Temperature（℃）	Corresponding models
Part Number	Resistance (Ω)	Tolerance (%)	Operating Temperature（℃）	Corresponding models
LPTC83-110	R25=1000	±1%	-40℃～150℃	KTY83-1KΩseries
LPTC83-120	R25=1000	±2%
LPTC83-121	R25=1000	-2%
LPTC83-122	R25=1000	+2%
LPTC83-150	R25=1000	±5%
LPTC83-151	R25=1000	-5%
LPTC83-152	R25=1000	+5%
LPTC81-110	R25=1000	±1%	-55℃～+150℃	KTY81-1KΩ series
LPTC81-120	R25=1000	±2%
LPTC81-121	R25=1000	-2%
LPTC81-122	R25=1000	+2%
LPTC81-150	R25=1000	±5%
LPTC81-151	R25=1000	-5%
LPTC81-152	R25=1000	+5%
LPTC81-210	R25=2000	±1%	-55℃～+150℃	KTY81-2KΩ series
LPTC81-220	R25=2000	±2%
LPTC81-221	R25=2000	-2%
LPTC81-222	R25=2000	+2
LPTC81-250	R25=2000	±5%
LPTC81-251	R25=2000	-5%
LPTC81-252	R25=2000	+5%
LPTC84-130	R100=1000	±3%	-40℃～+180℃	KTY84 series
LPTC84-150	R100=1000	±5%
LPTC84-151	R100=1000	-5%
LPTC84-152	R100=1000	+5%
LPTC-200	R25=200	±3%；+5%、-5%	-40℃～+160℃
LPTC-500	R25=500	±3%；+5%、-5%	-40℃～+160℃
LPTC-1200	R25=1200	±3%；+5%、-5%	-50℃～+125℃
LPTC-1600	R25=1600	±3%；+5%、-5%
LPTC-3000	R25=3000	±3%
LPTC-4000	R25=4050	±3%
